Racing semi-automatic swing arm tire changer, expressly designed for oversize and racing tires. It's suitable for wheels with a rim from 14" to 26" (max. tire diameter 1143 mm./45", max. tire width 406mm./16"). It's suggested for high volume tire shops.
Features:
1. 009+098 help arm system: The higher position installed help arms design allowing a more flexible operation. Available to lock the arm at any position that needs.
2. Adopt rugged & durable one-piece casting jaws
3. Adjustable pressing shovel helps to press tyre with less effort.
| Specification |
| Air supply pressure |
8-10bar (116-145 psi) |
| Optional power supply |
110v (1ph)/ 220v (1/3ph)/380v(3ph) |
| Motor power |
0.55/0.75/1.1 kw |
| Noise Level |
≤75 dB |
| Product |
Semi-automatic Swing Arm
|
| Product Code |
U-203 |
| External clamping |
12~23" |
| Internal clamping |
14~26" |
| Max.wheel diameter |
≤1143mm (45") |
| Max.wheel width |
≤406mm (16") |
| N/G weight |
212/240kg (466/528 lbs) |
| Package dimension |
900*1130*950mm (3.0*3.7*3.1ft) |
